I8-55S General Incinerator

I8-55S General Incinerator is one of our larger ‘S’ model, It is designed to deliver performance on a budget and be a simple and effective incinerator from our medium range with suitability for various non-hazardous waste types such as wood, paper, cardboard and other uncontaminated materials.

Our versatile range of ‘S’ model incinerators are designed to be multi-purpose. This particular model benefits from a top loading design and very simple operation process. Ideal as a stand-alone machine.

Overview

The addition of a secondary chamber allows this model to operate without smoke, odours or harmful emissions. Fitted with a secondary chamber with afterburner functionality for the re-burn of harmful emissions through a 0.5 second retention time.

Features

Enhanced Coretex insulation
Multi-zone temperature control
Mobile options available
CE2 Advanced control panel
Modular refractory lining

Categories: Incinerators, General Tags: General, incinerator Brand: Inciner8

Description
Reviews (0)

Applications

Camps
Military Operations
Remote Housing
Industrial Waste < 500kg day
< 150 People Comunities

Technical Specifications

Operational Specifications

Combustion Chamber Volume (m3): 0.36m3
Burn Rate*: up to 40kg per hour
Average Fuel Consumption: 10 – 12 ltrs p/h
Operational Temperature: > > 850°C
Gas Retention in Secondary Chamber: 0.5 secs
Temperature Monitoring: Yes
Average ash residue (%): 3%
Thermostatic Device: Yes

Physical Specifications

External Length (mm): 1520mm
External Width (mm): 920mm
External Height (mm): 4020mm
Door Size (mm): 720 x 830
Shipping Weight: 1670kg

For reference only, not to be used for installation purposes. * All burn rates are dependant on the calorific value of the waste being incinerate. Atmospheric conditions,fuel (gas/oil) quality, additional accessories (autoloader, de-asher) can also have a major impact on actual burn rates.
