Morningstar Prostar 30A Charge Controller

Get a quote

Morningstar Prostar 30A Charge Controller PS-30

Name: Morningstar Prostar 30A Charge Controller PS-30 - Melanite
SKU: PS-30

Morningstar Prostar 30A Charge Controller: high-reliability 30 A PWM regulator with LVD and temperature compensation for 12/24 V systems.

Product Details

Morningstar Prostar 30A Charge Controller is engineered for professional off-grid solar systems operating at 12 V or 24 V battery banks, delivering a full 30 amp charge and load rating. The Morningstar Prostar 30A Charge Controller offers built-in low-voltage disconnect (LVD) to safeguard your battery, integrated temperature compensation (TC) to optimise charging performance across environmental conditions, and selectable battery chemistry options for sealed, gel and flooded types. With the Morningstar Prostar 30A Charge Controller you get fan-free thermal design, rugged industrial construction, and a proven track record with the Morningstar Prostar series trusted in harsh environments. Choose the Morningstar Prostar 30A Charge Controller for reliable, scalable battery regulation and intelligent load control in mission-critical solar installations.

SKU: PS-30 Categories: Solar Energy, Charge Controller Tag: Morningstar Charge Controller Brand: Morningstar

Description
Reviews (0)

Product Description

The Morningstar Prostar 30A Charge Controller delivers dependable and efficient battery management for 12 V or 24 V solar systems requiring a 30-amp solution. The Morningstar Prostar 30A Charge Controller uses high-precision PWM (pulse-width modulation) charging with four-stage profiles — bulk, absorption, float and equalise — combined with temperature compensation (TC) to extend battery life and improve system performance. The Morningstar Prostar 30A Charge Controller features low-voltage disconnect (LVD) protection to prevent deep discharge, solid-state design without mechanical moving parts for longevity, and comprehensive electronic protections (reverse polarity, overcurrent, high temperature) for rugged reliability. Ideal for residential off-grid homes, remote lighting systems, telecom backup, marine power and rural electrification, the Morningstar Prostar 30A Charge Controller adapts to diverse applications. Backed by the heritage of the Morningstar Prostar line—installed in hundreds of thousands of systems worldwide—the Morningstar Prostar 30A Charge Controller offers peace of mind, scalability and industry-leading quality for demanding solar installations.

Product Specification

Model	PS-15	PS-15M	PS-30	PS-30M
Charge Rating	15 amps	15 amps	30 amps	30 amps
Max. PV Open Circuit Voltage (Voc) for 12/24V batteries	30/60 volts	30/60 volts	30/60 volts	30/60 volts
Nominal Battery Voltage	12V or 24V	12V or 24V	12V or 24V	12V or 24V
Battery Chemistry Supported	L/A, Li, NiCd, others	L/A, Li, NiCd, others	L/A, Li, NiCd, others	L/A, Li, NiCd, others
Battery Voltage Range	10-35V	10-35V	10-35V	10-35V
Voltage Accuracy	<=0.1% +/- 50mV	<=0.1% +/- 50mV	<=0.1% +/- 50mV	<=0.1% +/- 50mV
Operating Temperature Range	-40 C to +60C	-40 C to +60C	-40 C to +60C	-40 C to +60C
Warranty	5 Years	5 Years	5 Years	5 Years
Built-in meter	No	Yes	No	Yes
CE and RoHS compliant	Yes	Yes	Yes	Yes
TAA compliant	Yes	Yes	Yes	Yes
Approved for use in Hazardous Locations: Class 1, Division 2, Groups A-D	Yes	Yes	Yes	Yes
IEC 62109	Yes	Yes	Yes	Yes
ETL Listed [UL-1741 and Canadian CSA C22.2 No.107.1.01]	Yes	Yes	Yes	Yes
FCC Class B Part 15 Compliant	Yes	Yes	Yes	Yes
Manufactured in a Certified ISO 9001 Facility	Yes	Yes	Yes	Yes
