I8-M40 Medical Incinerator

I8-M40 Medical Incinerator is a simple and effective medical incinerator. It was deisgned for small clinics, dental practices or small medical facilities where waste streams are quite low.

The top-loading design means liquids are well contained within this system during incineration. Featuring inbuilt afterburners, the i8-M40 ensures harmful emissions are eradicated with ease.

Overview

The i8-M40 is a medium capacity model from our range of specialist “M” incinerators. The addition of an advanced CE2-VFD control panel, I.D. fan and increased insulation improves performance and provides all-round suitability for many different types of medical, clinical, pharmaceutical and hazardous waste streams.

Features

Enhanced Coretex insulation
Multi-zone temperature control
Mobile options available
CE2-VFD Advanced control panel
Tertiary air control

Categories: Incinerators, Medical Tags: incinerator, Medical Brand: Inciner8

Description
Reviews (0)

Download Datasheet

Applications

Medical Laboratories
Dental / Cosmetic Clinics
Blood Banks / Collection
< 250 Bed Medical Facilities
Medical Facilities

Technical Specifications

Operational Specifications

Combustion Chamber Volume (m3): 0.36m3
Burn Rate*: up to 30kg per hour
Average Fuel Consumption: 9 – 11 ltrs p/h
Operational Temperature: > > 850°C
Gas Retention in Secondary Chamber: 2 secs
Temperature Monitoring: Yes
Average ash residue (%): 3%
Thermostatic Device: Yes

Physical Specifications

External Length (mm): 1240mm

External Width (mm): 920mm

External Height (mm): 4400mm

Door Size (mm): 0.56 x 0.56

Shipping Weight: 1520kg

For reference only, not to be used for installation purposes. * All burn rates are dependant on the calorific value of the waste being incinerate. Atmospheric conditions,fuel (gas/oil) quality, additional accessories (autoloader, de-asher) can also have a major impact on actual burn rates.
