I8-700G General Incinerator

I8-700G General Incinerator is the established ‘powerhouse’ amongst our large-scale incinerators. The second biggest model in our general range it was designed to outperform any other incinerator within its class.

This model can be customized with external cladding and automatic loading to provide an effective and sustainable waste disposal solution for many different types of industries with large volumes of waste such as RDF, SRF and MSW.

Overview

We offer a plethora of options in terms of pre-processing and post-combustion – all geared to increasing the performance and efficiency of this unit. The top-loading design provides liquid retention making this incinerator ideal for the incineration of many different waste streams. Unless specified this model uses our NX PLC range of control panels.

Features

Enhanced Coretex insulation
Multi-zone temperature control
Additional safety features
CE2 Advanced control panel
Hydraulic doors

Categories: Incinerators, General Tags: General, incinerator Brand: Inciner8

Description
Reviews (0)

Download Datasheet

Applications

Landfill Alternative
Recycling Centres
Bigger Camps
< 5000 People Communities
Industrial Waste < 8000kg day

Technical Specifications

Operational Specifications

Combustion Chamber Volume (m3): 6.75m3
Burn Rate*: up to 400kg per hour
Average Fuel Consumption: 40 – 50 ltrs p/h
Operational Temperature: > 850°C
Gas Retention in Secondary Chamber: 2 secs
Temperature Monitoring: Yes
Average ash residue (%): 3%
Thermostatic Device: Yes

Physical Specifications

External Length (mm): 6040mm
External Width (mm): 1910mm
External Height (mm): 5750mm
Door Size (mm): 4580 x 1500mm
Shipping Weight: 15000kg

For reference only, not to be used for installation purposes. * All burn rates are dependant on the calorific value of the waste being incinerate. Atmospheric conditions,fuel (gas/oil) quality, additional accessories (autoloader, de-asher) can also have a major impact on actual burn rates.
