I8-40G General Incinerator

I8-40G General Incinerator builds upon the success of our i8-20G and is a simple and effective incinerator from our small range. It excels due to its suitability for various non-hazardous waste types such as wood, paper, cardboard and other uncontaminated materials.

The i8-40G General Incinerator fits right in the middle of our standard range in terms of capacity and is a simple, effective multi-purpose incinerator with suitability for disposing of general and medical waste.

Overview

This unit benefits from an advanced secondary chamber with afterburner for the re-burn of harmful emissions with a 2 second retention time.

Giving you a reliable total waste solution.

Features

Enhanced Coretex insulation
Multi-zone temperature control
Mobile options available
CE2 Advanced control panel
Small operating footprint

Categories: Incinerators, General Tags: General, incinerator Brand: Inciner8

Description
Reviews (0)

Download Datasheet

Applications

Camps
Military Operations
OiI & Gas Facilities
< 120 People Communities
Industrial Waste < 500kg day

Technical Specifications

Operational Specifications

Combustion Chamber Volume (m3): 0.36m3
Burn Rate*: up to 30kg per hour
Average Fuel Consumption: 9 – 11 ltrs p/h
Operational Temperature: > > 850°C
Gas Retention in Secondary Chamber: 2 secs
Temperature Monitoring: Yes
Average ash residue (%): 3%
Thermostatic Device: Yes

Physical Specifications

External Length (mm): 1240mm
External Width (mm): 920mm
External Height (mm): 4400mm
Door Size (mm): 560 x 560
Shipping Weight: 1520kg

For reference only, not to be used for installation purposes. * All burn rates are dependant on the calorific value of the waste being incinerate. Atmospheric conditions,fuel (gas/oil) quality, additional accessories (autoloader, de-asher) can also have a major impact on actual burn rates.
