Morningstar SunSaver Charge Controller SS-6-12V

Name: Morningstar SunSaver Charge Controller SS-6-12V - Melanite
SKU: SS-6-12V

Morningstar SunSaver Charge Controller: ultra-reliable 6 A PWM regulator with temperature compensation, perfect for 12/24 V off-grid systems.

Product Details

Morningstar SunSaver Charge Controller is a premium solar charge regulator rated for 6 amps, designed for 12 V (and selected 24 V) systems and equipped with temperature compensation and full electronic protection. The Morningstar SunSaver Charge Controller features four-stage PWM charging, low self-consumption, and robust encapsulated construction ideal for harsh environments. With the Morningstar SunSaver Charge Controller you gain sealed or flooded battery settings, accurate regulation to ±25 mV, and a design certified for hazardous locations. The Morningstar SunSaver Charge Controller supports remote homes, lighting systems, agriculture and industrial monitoring—making the Morningstar SunSaver Charge Controller a dependable choice for designers seeking long-term, low-maintenance solar battery regulation.

SKU: SS-6-12V Categories: Solar Energy, Charge Controller Tag: Morningstar Charge Controller Brand: Morningstar

Description
Reviews (0)

Product Description

The Morningstar SunSaver Charge Controller is a highly dependable 6 amp PWM solar regulator tailored for small to mid-scale 12 V (and some 24 V) off-grid battery systems. The Morningstar SunSaver Charge Controller uses advanced four-stage PWM charging techniques—bulk, absorption, float and equalize—coupled with temperature compensation to adjust charging parameters for ambient conditions and extend battery life. The Morningstar SunSaver Charge Controller incorporates full electronic protection including overload, short-circuit, reverse polarity and high-voltage surge tolerance, and is built using solid-state MOSFET design with fan-free, epoxy-encapsulated enclosure to withstand extreme environments (-40 °C to +60 °C). The Morningstar SunSaver Charge Controller supports sealed or flooded battery profile selection, offers extremely low self-consumption (<8 mA), and is certified for use in hazardous locations, making the Morningstar SunSaver Charge Controller ideal for applications such as remote cabins, solar lighting, telecom instrumentation, marine boats, rural electrification and oil & gas monitoring. With a legacy of over 1.5 million installations worldwide, the Morningstar SunSaver Charge Controller brings proven reliability, precision battery management and peace of mind for challenging solar installations.

Product Specification

Model	SS-6-12V	SS-6L-12V	SS-10-12V	SS-10L-12V	SS-10L-24V	SS-20L-12V	SS-20L-24V
Charge Rating	6 amps	6 amps	10 amps	10 amps	10 amps	20 amps	20 amps
Max. PV Open Circuit Voltage (Voc)	30 volts	30 volts	30 volts	30 volts	60 volts	30 volts	60 volts
Nominal Battery Voltage	12V	12V	12V	12V	24V	12V	24V
Minimum Battery Voltage	6V	6V	6V	6V	6V	6V	6V
Load Control	No	Yes	No	Yes	Yes	Yes	Yes
Voltage Accuracy	+/- 25mV	+/- 25mV	+/- 25mV	+/- 25mV	+/- 48mV	+/- 25mV	+/- 48mV
Operating Temperature Range	-40 C to +60C	-40 C to +60C	-40 C to +60C	-40 C to +60C	-40 C to +60C	-40 C to +60C	-40 C to +60C
Warranty	5 Years	5 Years	5 Years	5 Years	5 Years	5 Years	5 Years
CE and RoHS compliant	Yes	Yes	Yes	Yes	Yes	Yes	Yes
TAA compliant	Yes	Yes	Yes	Yes	Yes	Yes	Yes
Approved for use in Hazardous Locations: Class 1, Division 2, Groups A-D	Yes	Yes	Yes	Yes	Yes	Yes	Yes
ETL Listed [UL-1741 and Canadian CSA C22.2 No.107.1.01]	Yes	Yes	Yes	Yes	Yes	Yes	Yes
FCC Class B Part 15 Compliant	Yes	Yes	Yes	Yes	Yes	Yes	Yes
Manufactured in a Certified ISO 9001 Facility	Yes	Yes	Yes	Yes	Yes	Yes	Yes
