Morningstar 60A Charge Controller TS-60-MPPT

Name: Morningstar 60A Charge Controller TS-60-MPPT - Melanite
SKU: TS-MPPT-60

Morningstar 60A Charge Controller – 60 A MPPT solar controller for 12-48 V systems with 99% efficiency and advanced network monitoring.

Product Details

Morningstar 60A Charge Controller delivers a robust continuous 60 amp charge rating suitable for 12 V, 24 V, 36 V or 48 V battery banks. The Morningstar 60A Charge Controller supports PV open-circuit voltages up to 150 V and delivers up to 3.2 kW of nominal operating power on a 48 V battery configuration. With peak efficiency of 99%, the Morningstar 60A Charge Controller uses advanced TrakStar™ MPPT tracking to maximise solar harvest. The Morningstar 60A Charge Controller includes Ethernet, RS-232, EIA-485 connectivity for remote monitoring and data‐logging, and a fanless thermal design for high reliability. Choose the Morningstar 60A Charge Controller for mission-critical off-grid solar systems requiring dependable performance and intelligent control.

SKU: TS-MPPT-60 Categories: Solar Energy, Charge Controller Tag: Morningstar Charge Controller Brand: Morningstar

Description
Reviews (0)

Product Description

The Morningstar 60A Charge Controller from the TriStar MPPT family is engineered for high-performance off-grid photovoltaic installations where efficiency, reliability and monitoring matter most. The Morningstar 60A Charge Controller employs TrakStar™ MPPT technology to continuously sweep the I-V curve of the solar array, enabling world-class peak efficiency of up to 99% and capturing maximum energy even under shading or mixed-module conditions. This Morningstar 60A Charge Controller supports battery systems ranging from 12 V to 48 V and can handle PV open-circuit voltages up to 150 V, making it versatile across residential, commercial and industrial installations. With built-in Ethernet port and RS-232/EIA-485 communications, the Morningstar 60A Charge Controller offers system monitoring, data logging and remote adjustability — ideal for remote cabins, telecom sites, marine vessels, RVs or rural electrification. Built with a fanless design, oversized heatsink and full electronic protections (reverse polarity, over-current, over-temperature, PV short circuit) the Morningstar 60A Charge Controller delivers long-term durability and unattended reliability. In short, if you need a single controller that optimizes solar charging, maintains battery health and communicates real-time system performance, the Morningstar 60A Charge Controller is an excellent choice.

Product Specification

Model	TS-MPPT-30	TS-MPPT-45	TS-MPPT-60	TS-MPPT-60M
Charge Rating	30 amps	45 amps	60 amps	60 amps
Max. PV Open Circuit Voltage (Voc)	150 volts	150 volts	150 volts	150 volts
Nominal Battery Voltage	12, 24, 36, or 48V	12, 24, 36, or 48V	12, 24, 36, or 48V	12, 24, 36, or 48V
Battery Chemistry Supported*	L/A, Li, NiCd, others	L/A, Li, NiCd, others	L/A, Li, NiCd, others	L/A, Li, NiCd, others
Nominal max. Operating Power** – 12 volt battery	400W	600W	800W	800W
Nominal max. Operating Power** – 24 volt battery	800W	1200W	1600W	1600W
Nominal max. Operating Power** – 48 volt battery	1600W	2400W	3200W	3200W
Peak efficiency	99%	99%	99%	99%
Battery Operating Voltage Range	8-72Vdc	8-72Vdc	8-72Vdc	8-72Vdc
Voltage Accuracy (12/24V)	<=0.1% +/- 50mV	<=0.1% +/- 50mV	<=0.1% +/- 50mV	<=0.1% +/- 50mV
Voltage Accuracy (48V)	<=0.1% +/- 100mV	<=0.1% +/- 100mV	<=0.1% +/- 100mV	<=0.1% +/- 100mV
Operating Temperature Range	-40 C to +45C	-40 C to +45C	-40 C to 45C	-40 C to +45C
Warranty	5 Years	5 Years	5 Years	5 Years
Built-in meter				Yes
CE and RoHS compliant	Yes	Yes	Yes	Yes
TAA compliant	Yes	Yes	Yes	Yes
IEC 62109	Yes	Yes	Yes	Yes
ETL Listed [UL-1741 and Canadian CSA C22.2 No.107.1.01]	Yes	Yes	Yes	Yes
FCC Class B Part 15 Compliant	Yes	Yes	Yes	Yes
Manufactured in a Certified ISO 9001 Facility	Yes	Yes	Yes	Yes
